Are All Electric Vehicle Chargers The Same?

When undergoing an electric vehicle charger installation it is important to know what charger needs to be installed. Different electric vehicles will require different charging plugs while choosing what level ev charger is important. Here at The Local Electrician, we offer professional electric vehicle charging station installation and repairs for Sydney. Our team will install the ev charging station into any building and can work with all electric vehicle chargers

Not all electric vehicle chargers are the same as there are different plug types and charging station types. The model and brand of the electric car will also influence what electric car charging station can be used. When planning on purchasing an ev home charging station knowing what specific charger is needed to charge the car is essential.

Google Rating
4.8
Based on 284 reviews
js_loader

What are the Different Levels of Electric Vehicle Chargers?

There are three types of levels of charging that EV chargers can be at. Some cars will need specific levels of charging while others prefer different chargers over others. A guide to the different levels of charging with electric vehicle chargers are:

Charger Level Charging Times with Distance Traveled
Level 1 – 240V 1.4kW 7.5km-14km per hour
Level 2 – 240V 3.3KW-6.6kW 18-40km per hour
Level 3 – DC Fast Charger 70km per 10 minutes or 420km per hour

Level 1 Charging

Level 1 chargers are best suited for cars with smaller battery sizes or when charging the car for long periods of time is possible. These chargers are able to be plugged into simple electrical outlets and are best for home chargers. When limited space for a whole charging station is available, such as people living in units, level 1 charging is also suitable. As they require simple outlets they can also be brought onto road trips as well for people who drive petrol-hybrid electric vehicles.

It is recommended that people who drive 40km a day can utilise level 1 charging. This means though that it is only recommended for people who drive less than 4000km a year as charging is slower.

Level 2 Charging

Level 2 chargers are more powerful than level 1 and can still be plugged into their own simple outlet. This type of electric vehicle charger is the most common for homes and also public spaces as it offers a wide range of charging speeds. With its high charging speed range level, 2 chargers need their own dedicated circuit because it will need more electrical power.

It is recommended if possible to install a level 2 charging station at home. This is because it is more convenient, powerful and is faster at having the car fully charged. For home ev charger installation and also for businesses that offer ev charging station level 2 chargers are the way to go.

Level 3 Charging

Level 3 chargers use DC power and upgrading the switchboard from single phase to three phase is often needed. These chargers can quickly charge electric vehicles as they are able to draw out more power. Because they are expensive though they are mainly seen in petrol stations, street side charging and in certain commercial areas.

What are the Different Plugs of Electric Vehicle Chargers?

There are three main types of plugs used in electric car charging infrastructure:

  • Type 1 – J1772 – this plug has five pins on it which will communicate with the charger and the car with how much current is needed. This is to help protect the battery and ensure that the car is not being charged for more than it needs to be. Three of the pins are used for the AC power and this type of plug mainly complies with Japanese ev charging standards.
  • Type 2 – Mennekes – these plugs are the standard ones used across Australia which can be used for both electric and hybrid cars. There are seven pins where the extra two are used for three phase charging.
  • Type 3 – CHAdeMO – these plugs are mainly used for cars and stations that require DC power. This is because they charge quicker and use more power, which is why they are not as common.

Can All Electric Cars Use Tesla Chargers?

Tesla chargers, and especially the Tesla Supercharger, are great charging stations that efficiently charge the car. It is important to know though that only Tesla cars can charge with Tesla stations. This is the same with other brands where most electric vehicles can only be charged with the specific brand charging station. As technology with electric vehicles develops in the future charging any car at any station may be possible though.

Professional Electric Vehicle Charger Installation Services

The Local Electrician is here to work with electric vehicle chargers and perform top quality electric vehicle charger installation. Our fully qualified electricians are able to install these systems into any property reliably. The Emergency Electrician will have the ev charger installed safely and ensure it functions correctly after installation. We also offer reliable repairs with electric vehicle chargers where we will reliably repair any damages to the system.

Our electric vehicle charger services are here for all of Sydney, including Inner West and Eastern Suburbs. We are also Level 2 Electrician specialists where we will carry out advanced work, such as upgrading electrical switchboards needed for electric vehicle charging stations.

electric-vehicle-charger-installation-the-local-electrician

For the best electric vehicle charger installation services – trust The Local Electrician today!
